Turcon® Variseal® HF Flange Seals for Internal Pressure
The Trelleborg Turcon® Variseal® HF is a single-acting axial/face sealing element comprised of a U-shaped Turcon® ring and a coiled metallic energizing spring. This design ensures gas-tight sealing even at low temperatures. It is resistant to most liquids and chemicals and has unlimited shelf life.
Size Range:
6 mm to 200 mm
Temperature:
-200 °C to 260 °C
Pressure (max):
60 MPa
Material Information for the product(s) on this page
T05S
Basic Material:
PTFE/metal
Commercial Description:
Turcon® T05 is a PTFE-based material offering low friction and very good sealing properties and is widely recognized by its turquoise color. This material has a high percentage of PTFE and offers good performance in low-pressure, light-duty applications. Comes with a stainless steel spring.
| Product No. | Groove outside diameter d7 H11 | Groove Width, b4 | Groove depth, h | Material Type | Add to Enquiry | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Product No.DVE200320-T05S | Groove outside diameter d<sub>7</sub> H11 32 | Groove Width, b4 4.8 | Groove depth, h 3.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE200350-T05S | Groove outside diameter d<sub>7</sub> H11 35 | Groove Width, b4 4.8 | Groove depth, h 3.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE200360-T05S | Groove outside diameter d<sub>7</sub> H11 36 | Groove Width, b4 4.8 | Groove depth, h 3.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE200400-T05S | Groove outside diameter d<sub>7</sub> H11 40 | Groove Width, b4 4.8 | Groove depth, h 3.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE200450-T05S | Groove outside diameter d<sub>7</sub> H11 45 | Groove Width, b4 4.8 | Groove depth, h 3.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE300650-T05S | Groove outside diameter d<sub>7</sub> H11 65 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE300700-T05S | Groove outside diameter d<sub>7</sub> H11 70 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE300750-T05S | Groove outside diameter d<sub>7</sub> H11 75 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE300800-T05S | Groove outside diameter d<sub>7</sub> H11 80 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE300900-T05S | Groove outside diameter d<sub>7</sub> H11 90 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE300950-T05S | Groove outside diameter d<sub>7</sub> H11 95 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE301000-T05S | Groove outside diameter d<sub>7</sub> H11 100 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE301100-T05S | Groove outside diameter d<sub>7</sub> H11 110 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE301200-T05S | Groove outside diameter d<sub>7</sub> H11 120 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE301220-T05S | Groove outside diameter d<sub>7</sub> H11 122 | Groove Width, b4 7.1 | Groove depth, h 4.7 | Material Type [PTFE/metal] | ||||||
| Product No.DVE401250-T05S | Groove outside diameter d<sub>7</sub> H11 125 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE401400-T05S | Groove outside diameter d<sub>7</sub> H11 140 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE401600-T05S | Groove outside diameter d<sub>7</sub> H11 160 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE401700-T05S | Groove outside diameter d<sub>7</sub> H11 170 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE401800-T05S | Groove outside diameter d<sub>7</sub> H11 180 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE401900-T05S | Groove outside diameter d<sub>7</sub> H11 190 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE402000-T05S | Groove outside diameter d<sub>7</sub> H11 200 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE402100-T05S | Groove outside diameter d<sub>7</sub> H11 210 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE402300-T05S | Groove outside diameter d<sub>7</sub> H11 230 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
| Product No.DVE403200-T05S | Groove outside diameter d<sub>7</sub> H11 320 | Groove Width, b4 9.5 | Groove depth, h 6.1 | Material Type [PTFE/metal] | ||||||
